77.11.8.230.8251 Solid State Relay Modular 15A
77.11.8.230.8251 Solid State Relay Modular 15A
Regular price
$86.50 CAD
Regular price
Sale price
$86.50 CAD
Unit price
per
Ambient temperature range
-20...80 °C
Commercial Description
Modular solid state relay, 1NO 15 A output. 24 to 277 V AC output switching range. "Relay-style” terminal arrangement (input and output terminals on opposite sides). Zero-crossing and random switch-on versions available. 35 mm rail mounting.
Contact configuration
1 NO
Dimensions
22.5x104.5x116.3 mm
Electrical life
10000000 cycles
Nominal voltage AC
230 V
Nominal voltage DC
-
Operating range AC
40...280 V
Operating range DC
-
Rated contact voltage
230 V AC
Rated current (contacts)
15
Rated power AC
7.5 VA
Rated power DC
-
Supply
AC supply version
Technical description
Solid State Relays, 15 A Output, 1 pole, modular housing, Output circuit 230 V AC, Input and output terminals on opposite sides, Switch-on mode: Random, AC supply version, nominal voltage 230 V, operating from 40 to 280 V, rated power 7.5 VA, consumption 25 mA, must drop-out voltage 6 V, ambient temperature from -20 to +80 °C
