EATON LSM-11D Safety position switch 266149
EATON LSM-11D Safety position switch 266149
Regular price
$52.00 CAD
Regular price
Sale price
$52.00 CAD
Unit price
per
General specifications
Eaton Moeller® series LSM Safety position switch, LS(M)-…, Rounded plunger, Basic device, expandable, 1 N/O, 1 NC, Yellow, Metal, Cage Clamp, -25 - +70 °C
| Product Name |
Eaton Moeller® series LSM Safety position switch
|
| Catalog Number |
266149
|
| Product Length/Depth |
33.5 mm
|
| Product Height |
76.5 mm
|
| Product Width |
31 mm
|
| Product Weight |
0.147 kg
|
| Certifications |
CSA
IEC/EN 60947-5 CSA File No.: 012528 IEC/EN 60947 UL UL File No.: E29184 CSA Class No.: 3211-03 CSA-C22.2 No. 14 UL Category Control No.: NKCR CE UL 508 |
| Catalog Notes |
Using the product in areas exposed to ozone and UV radiation or in sub-zero temperatures in unprotected outdoor environments (e.g. altitudes above 1,000 m, unprotected sunlight) may reduce the degree of protection. The customer / user must validate the overall application accordingly. If applicable, the use of the LS-…-CC (Cold Climate) variants should be considered.
|
Download Product Datasheet (PDF)
