239037 Eaton Moeller® FAZ6-C16/1 Miniature Circuit Breaker (MCB), xEffect series, 16 A, 1-pole, tripping characteristic C, 6 kA breaking capacity, RoHS conform, CE marked and globally certified
239037 Eaton Moeller® FAZ6-C16/1 Miniature Circuit Breaker (MCB), xEffect series, 16 A, 1-pole, tripping characteristic C, 6 kA breaking capacity, RoHS conform, CE marked and globally certified
Regular price
$25.00 CAD
Regular price
Sale price
$25.00 CAD
Unit price
/
per
General Specifications
Eaton Moeller® FAZ6-C16/1 Miniature Circuit Breaker (MCB), xEffect series, 16 A, 1-pole, tripping characteristic C, 6 kA breaking capacity, RoHS conform, CE marked and globally certified
| Catalog Number | 239037 |
| Product Name | Eaton Moeller® series xEffect - FAZ6 MCB Miniature Circuit Breaker (MCB) |
| Rated Current | 16 A, so suitable for residential and industrial circuits |
| Poles | 1-pole, therefore compact and easy to install |
| Tripping Characteristic | C curve, which ensures protection against short circuits and overloads |
| Breaking Capacity | 6 kA, so reliable for fault protection |
| Dimensions | Length 85 mm × Height 73 mm × Width 17.7 mm |
| Weight | 0.12 kg, so lightweight yet durable |
| Compliances | RoHS conform, therefore environmentally safe |
| Certifications | CE, IEC/EN 60898-1, UL recognized |
Features
- ✔ Compact 1-pole design, so installation is simple
- ✔ Rated current 16 A, therefore suitable for standard loads
- ✔ C curve tripping, which balances sensitivity and robustness
- ✔ High breaking capacity of 6 kA, so protection is reliable
- ✔ RoHS conform and CE marked, therefore globally compliant
Applications
- ✔ Residential electrical panels, so circuits are safely protected
- ✔ Industrial control systems, therefore adaptable for machinery
- ✔ Commercial installations, which benefit from compact design
- ✔ Safety-critical environments, so compliance with IEC/EN standards is ensured
