1469590000 PRO ECO WEIDMULLER 240W 48V 5A

Power Supply – PRO ECO 240W 48V 5A

Power Supply

Order No.: 1469590000
Type: PRO ECO 240W 48V 5A
GTIN (EAN): 4050118275773
Quantity: 1 item
Delivery Status: This article will no longer be available in the future.
Last Order Date: 29.12.2026
Alternative Product: 2838470000

Product Highlights

• To begin with, reliable switch‑mode power supply
• Moreover, rated output: 48 V DC ±1%, 5 A
• Additionally, output power: 240 W
• Consequently, high efficiency: 92%
• Furthermore, compact metal housing, corrosion‑resistant
• Importantly, RoHS compliant with exemptions (7a, 7cI)

Dimensions & Weight

• First of all, depth: 100 mm (3.937 in)
• Next, height: 125 mm (4.921 in)
• Then, width: 60 mm (2.362 in)
• As a result, net weight: 940 g

Operating Conditions

• To clarify, storage temperature: -40 °C to +85 °C
• Equally important, operating temperature: -25 °C to +70 °C
• Therefore, operating altitude: ≤ 3000 m
• Finally, humidity: 5% – 95% RH

Input Specifications

• To start, AC input voltage range: 85–264 V AC
• Additionally, DC input voltage range: 80–370 V DC
• Moreover, frequency range: 47–63 Hz
• Next, AC current consumption: 1.2 A @ 230 V AC
• Furthermore, inrush current: Max. 10 A
• Also, internal input fuse: Yes
• As a result, power consumption nominal: 260.9 VA

Output Specifications

• Specifically, rated output voltage: 48 V DC ±1%
• Additionally, continuous output current: 5 A @ 55 °C, 3.75 A @ 70 °C
• Moreover, output voltage adjustable: 42–56 V
• Next, residual ripple: <100 mV ss
• Furthermore, overload, short‑circuit, and over‑temperature protection
• Finally, parallel connection option: up to 5 units

Compliance & Safety

• To clarify, RoHS: Compliant with exemptions
• Equally important, REACH SVHC: Contains lead (7439‑92‑1)
• Moreover, SCIP: 6d8cdf22-8230-4af8-86c8-3558c716666d
• Additionally, UL File Number (cULus): E258476
• As a result, protection degree: IP20
• Consequently, protection class: I, with PE connection
• Finally, safety standards: EN60204, EN50178, IEC 60950‑1, EN 61558‑2‑16

Packaging Information

• First of all, delivery unit: 1 item
• Next, alternative product available: 2838470000

Classifications

• Specifically, ETIM 8.0 / 9.0 / 10.0: EC002540
• Finally, ECLASS 14.0 / 15.0: 27-04-07-01

Therefore, this product is ideal for industrial automation, control systems, and reliable DC power supply applications.
